Warm Stage Microscope
Key Selling Points
- 7-inch HD 1080p screen built-in — real-time observation and group sharing
- 360° rotatable trinocular head — ergonomic viewing from any angle
- Dual stage options — single or dual-layer mechanical stage
- Photo & video capable — optional screen with recording functions
- Heating stage option — constant-temperature stage for live specimen work
- Ideal for teaching, clinical demonstration and documentation
Describe
BL-220TV-7.0 / BL-2208TV-7.0 Specifications
- Display: HD 7-inch screen, 1080p
- Observation Head: Trinocular (TV), 360° rotatable
- Interpupillary Distance: 55–75 mm
- Eyepiece: Wide-field WF10×
- Objectives: Achromatic 4×, 10×, 40×(Spring)
- Stage: Single-layer stage with moving ruler (110×120 mm) / Dual-layer mechanical stage with moving ruler (115×125 mm)
- Focusing: Coaxial coarse & fine focusing with axial division
- Nosepiece: 3-hole nosepiece
- Illumination: LED, adjustable brightness
- Optional Accessories: Constant-temperature heating stage; screen with photo and video functions
